Headline filters B360-80C 16 Bar

NEW HEADLINER FILTER (HF)  BRASS COALESING FILTRATION
PART NUMBER B360-80C
PORT SIZES:  1/4 NPT
DRAIN:   MANUAL BRASS PETCOCK 1/8 NPT
MAXIMUM PSIG:  250 PSIG
MAXIMUM TEMPERATURE:    80° C
MATERIAL: CZ121 BRASS /  INTERNALS: BLACK NYLON /  STANDARD GASKET: O-RING VITON)
DIMENSIONS:  155 MM  LONG,  57 MM WIDE
2 MOUNTING HOLE ON THE TOP 1/4-20 UNC X 12 MM DEEP ON 38 MM CENTERS @ 90° TO PORTS

ELEMENT:
80C ELEMENT IS USED TO REMOVE LARGE VOLUMES OF LIQUID & PARTICULATE AS WELL AS PROVIDING EXCELLANT FLOW RATE.
HIGH EFFICIENCY RATED AT 0.01 MICRON,  RESISTANT TO SALT WATER ATMOSPHERE
COALESCING AEROSOL REMOVAL APPLICATION, SPECIFICALLY DESIGNED FOR REMOVAL OF LIQUID AEROSOLS FROM GASES IN BOTH CORROSIVE & NONCORROSIVE APPLICATIONS. IT ALSO REMOVES PARTICULATES WITH THE SAME EFFICIENCY
BINDER TYPE:  PVDF FLUOROCARBON
MAXIMUM TEMPERATURE:  150°C
FILTRATION EFFICIENCY (REMONAL OF 0.01 MICRON PARTICLES) 75+ %
